$685.00
3 years limited warranty against manufacturing defect or poor workmanship; exclude consumable parts such as air filter and diaphragms.
UL outdoor rated for USA & Canada.
Specification
| Model | AL-100 | AL-120 | AL-150 | AL-200 | AL-250E |
|---|---|---|---|---|---|
| Voltage & Frequency | AC 120V, 230V, 240V & 50/60Hz | ||||
| Rated Pressure (kPa, psig) | 18, 2.6 | 20, 2.90 | |||
| Rated Performance (±5%) (lpm, cfm) | 100, 3.5 | 120, 4.2 | 150, 5.3 | 200, 7.0 | 250, 8.8 |
| Rated Input Power (W) | 120 | 124 | 160 | 261 | 295 |
| Sound Level (dB) | 41 | 42 | 44 | 45 | 46 |
| Discharge O.D. (mm, in) | 18, 5/8 | ||||
| Weight (kg, lb) | 8.3, 18.2 | 8.3, 18.2 | 10.1, 22.3 | 10.1, 22.3 | 10.1, 22.3 |
